IS200TPROH1C是GE開發的緊急保護（TPRO）終端板。三個 PPRO I/O 包安裝在緊急保護 （TPRO） 端子板上。它具有一對用于總線和發電機電壓輸入的電位變壓器 （PT），并為 PPRO 調節速度信號輸入。上面有三個 DC-37 針連接器，PPRO 組連接器的每一側一個。每個 DC-37 都接受通向 Mark* VIe 后備跳閘繼電器端子板的電纜。TPROH1C 有兩個可插拔模塊，每個模塊有 24 個屏障端子。
IS200TPROH1C適用于各種電氣系統，電鍍，電解行業中的交流大電流的測量和控制，該產品有以下幾個特點：
1.產品輸入無飽和：由于產品采用的是rogowski原理，摒棄了傳統的互感器原理或是霍爾原理中必須使用的磁芯，從而使得產品的輸入范圍可以做到很大而不影響產品的性能；
2.響應時間快：本產品響應時間可以達到us級別，可應用于電力系統中的故障錄波等方面；
3.產品頻響寬：本產品的頻寬范圍可以達到20khz以上，可廣泛應用于輸入波形復雜等信號檢測；
4.線性好：產品輸出的線性度可以達到0.2%，可以的反映輸入信號的大??；
5.精度高：產品整體的精度在1%以內；
6.體積小，重量輕：相比傳統的互感器原理和霍爾原理的產品，在相同輸入量程的條件下，本產品的體積更小，重量更輕；

IS200TPROH1C

The IS200TPROH1C is an Emergency Protection (TPRO) terminal board developed by GE. Three PPRO I/O packages are installed on the Emergency Protection (TPRO) terminal board. It has a pair of potential transformers (PT) for the bus and generator voltage input and regulates the speed signal input for the PPRO. There are three DC-37-pin connectors on it, one on each side of the PPRO group connector. Each DC-37 accepts a cable to the Mark* VIe backup trip relay terminal board. TPROH1C has two pluggable modules, each with 24 barrier terminals.
IS200TPROH1C is suitable for all kinds of electrical systems, electroplating, electrolysis industry AC high current measurement and control, the product has the following characteristics:
1. Product input saturation: Because the product adopts the rogowski principle, abandoning the traditional transformer principle or the Hall principle must be used in the magnetic core, so that the product input range can be large without affecting the performance of the product;
2. Fast response time: the response time of this product can reach us level, which can be applied to the fault recording of the power system;
3. Product frequency response width: the bandwidth range of this product can reach more than 20khz, can be widely used in the input waveform complex signal detection;
4. Good linearity: the linearity of product output can reach 0.2%, which can reflect the size of the input signal;
5. High accuracy: the overall accuracy of the product is within 1%;
6. Small volume, light weight: compared with the traditional transformer principle and Hall principle products, under the same input range, the product is smaller in volume and lighter in weight;

IS200TPROH1C
