AL81G在使用高頻超聲波信號的高速描中很受歡迎。它最常用于數字化來自UT340或其他高頻脈沖接收器的信號。AL81G它具有8位分辨率的單通道數字化功能，采樣頻率最高可達1 GHz。這提供了約40 dB的有用動態范圍，適合對高達約200 MHz中心頻率的RF信號進行數字化處理。
AL81G具有正交編碼器或步進和方向信號的單輸入。此功能使數字化儀能夠跟上高速掃描系統的運動。
應用實例:分辨率自動掃描儀、鼢辨率測厚、先進金屬、涂層和層壓板的探傷、超聲顯微鏡、實驗室掃描系統。

AL81G-

The AL81G is popular in high speed maps that use high frequency ultrasonic signals. It is most commonly used to digitize signals from UT340 or other high frequency pulse receivers. AL81G It has single-channel digitization with 8-bit resolution and sampling frequencies up to 1 GHz. This provides a useful dynamic range of about 40 dB, suitable for digitizing RF signals up to a center frequency of about 200 MHz.
The AL81G has an orthogonal encoder or single input for step and direction signals. This feature enables the digitizer to keep up with the movement of the high-speed scanning system.
Application examples: automatic resolution scanners, voluminescence thickness measurement, advanced metal, coating and laminate flaw detection, ultrasonic microscopy, laboratory scanning systems.

AL81G-
