伍德沃德的9907-1183人機界面可以配備N(xiāo)EMA 4X級保護外殼。雖然外殼是可選的，但建議使用它，因?yàn)樗軌蛴行У乇Ｗo(hù)機電部件免受任何永久性損壞。外殼防水、防塵，適用于惡劣的室外環境。

9907-1183型號配備了一個32位微控制器，允許控制各種渦輪機，如工業規模的標準汽輪機，公用事業渦輪發電機和渦輪膨脹機型號。它可以配置為獨立設備，也可以與工業工廠的DCS(分布式控制系統)串聯運行。該505E控制器設計用于操作提取和/或大多數汽輪機系統的入場。

該Woodward HMI具有PID結構，非常適合需要監視和控制渦輪速度，負載，入口壓力，排氣集箱壓力或提取/入口集箱壓力等參數的應用。通過4-20 mA換能器和PID，以及比率/限制器功能，9907-1183精確控制提取/進入，同時保護渦輪機不受其參數外的操作。

9907-1183

Woodward’s 907-1183 HMI can be equipped with a NEMA 4X-rated protective housing. Although the housing is optional, it is recommended to use it because it is effective in protecting the electromechanical parts from any permanent damage. The housing is waterproof and dust-proof, suitable for harsh outdoor environments.

Models 9907-1183 are equipped with a 32-bit microcontroller that allows control of a variety of turbines, such as industrial-scale standard steam turbines, utility turbine generators and turbine expansion models. It can be configured as a standalone device or run in series with a DCS(distributed control system) in an industrial plant. The 505E controller is designed to operate the extraction and/or entry of most steam turbine systems.

The Woodward HMI features a PID construction that is ideal for applications where parameters such as turbine speed, load, inlet pressure, exhaust header pressure or extraction/inlet header pressure need to be monitored and controlled. With a 4-20 mA transducer and PID, as well as a ratio/limiter function, the 9907-1183 precisely controls extraction/entry while protecting the turbine from operations outside its parameters.

9907-1183

9907-1183
