T9110 處理器

【產品詳情】

本手冊中的故障診斷程序?qū)⑨槍?duì)單個故障找到解決方案。如果您遵循其中一個流程直至其結束，但如果故障指示仍然存在，則存在其他故障。隔離在首次調查期間已刪除的故障組件，然后重復故障查找過程。所需工具標準AADvance
AADvance控制器的安裝和維護需要以下工具和測試設備:
標準工具螺絲刀，扁0.8。Mm x 9.0 Mm(1/25英寸x 3/8英寸)，用于模塊夾緊螺釘和下料蓋板平底螺絲刀，0.6 mm x 3.0 mm(1/40英寸x 1/8英寸)，或類似的，將打開接線組件上的保險絲蓋·螺絲刀，十字頭0，用于9110處理器模塊上的電池蓋
十字螺絲刀，扁型0.8 mm x 4.0 mm(1/25英寸x 5/32英寸)，用于固定延長線
力矩螺絲刀，扁型0.6 mm x 3.0 mm(1/40英寸x 1/8英寸)，用于直流電源接線端子力矩螺絲刀，扁型0.4 mm x 2.0 mm(1/64英寸x 5/64英寸)，用于現場接線端子
2個扳手，開口，10mm，用于接地螺柱螺母
Allen鍵(六角扳手)，2.5 mm，用于插頭和插座組件與延長電纜
特殊的工具
長嘴鉗，用于拆卸終端組件上的保險絲
數字電壓表，用于故障排除活動
電阻1k8，用于故障排除模擬輸入模塊
電阻1k 1W，用于數字輸出模塊故障排除
電陽250R1W，用于故障排除模擬輸出模塊

T9110

The troubleshooter in this manual will find a solution for a single fault. If you follow one of these processes until its end, but if the fault indication still exists, there are other faults. Isolate the failed components that were removed during the first survey, and then repeat the troubleshooting process. Required tools standard AADvance
The following tools and test equipment are required for AADvance controller installation and maintenance:
Standard tools Screwdriver, 0.8 flat. Mm x 9.0 Mm(1/25 “x 3/8”) Flat-bottom screwdriver for module clamping screws and blanking covers, 0.6 mm x 3.0 mm(1/40 “x 1/8”), or similar, will open the fuse cover on the wiring assembly · Screwdriver, cross head 0, For the battery cover on the 9110 processor module
Phillips screwdriver, flat 0.8 mm x 4.0 mm(1/25 inch x 5/32 inch), used to secure extension cables
Torque screwdriver, flat 0.6 mm x 3.0 mm(1/40 inch x 1/8 inch), used for DC power terminal Torque screwdriver, flat 0.4 mm x 2.0 mm(1/64 inch x 5/64 inch), used for field terminal
2 wrenches, open, 10mm, for grounding stud nuts
Allen key (hex wrench), 2.5 mm, for plug and socket assemblies with extension cables
Special tool
Long nose pliers used to remove fuses from terminal components
Digital voltmeter for troubleshooting activities
Resistance 1k8 for the troubleshooting analog input module
Resistance 1k 1W for troubleshooting of digital output module
Positive 250R1W, used for troubleshooting analog output module

T9110
