制造商：ICS Triplex

產品編號：T8311

產品類型：可信 TMR 擴展器接口

電壓范圍：20 至 32V dc

散熱量：40W

搭配機箱使用：T8300

最大負載：40W

模塊時鐘：50MHz

擴展器總線數據速率：250Mbps

制造商：ICS Triplex

I/O 接口：擴展機箱背板

工作溫度：-5°C 至 60oC（13°F 至 140°F）

非工作溫度：-25°C 至 70oC（-25°F 至 158°F）

T8311

如果對位置和速度有一定的精度要求，而對實時轉矩不是很關心，用速度或位置模式比較好。

如果上位控制器有比較好的閉環控制功能，用速度控制效果會好一點。T8311如果本身要求不是很高，或者基本沒有實時性的要求，用位置控制方式對上位控制器沒有很高的要求。

對運動中的動態性能有比較高的要求時，需要實時對電機進行調整。

如果控制器本身的運算速度很慢（比如PLC，或低端運動控制器），T8311就用位置方式控制。

如果控制器運算速度比較快，可以用速度方式，把位置環從驅動器移到控制器上，減少驅動器的工作量，提高效率；

TrustedTM TMR T8311擴展器接口模塊位于TrustedTM控制器機箱和在控制器機箱中的模塊間總線（IMB）和

擴展器總線。擴展器總線允許使用UTP實現多個機箱系統電纜連接，同時保持容錯、高帶寬IMB功能。

模塊為擴展器總線、模塊本身和模塊中的IMB提供故障遏制

控制器底盤，確保這些潛在故障的影響是局部的，并且系統最大限度地提高可用性。該模塊采用Shift TMR體系結構，具有容錯性。綜合的

診斷、監控和測試可快速識別故障。熱備用和模塊備用支持插槽配置，允許自動和手動修復策略。

T8311

ICS TRIPLEX T8231 Trusted Power System
ICS TRIPLEX T8231 Trusted Power System
The Trusted Power system is a high density flexible power supply designed to convert main line voltages of 110 Vac or 240 Vac. The output of the trusted product is 24 Vdc or 24 Vdc adjustable field power supply.
The Trusted Power system consists of a mechanically supported 1U power rack containing up to three 750 W power packs. Power packs share the load in a configuration that uses one or more power racks. Each power pack has a separate power connection via a mechanically held cross-type connector. Each power rack can provide 2250 W of power or 1500 W of power, with n+1 yuan remaining from a single power supply. Multiple units can be connected to meet further capacity or redundancy requirements
The diagnostic information about the status of the power supply group is provided through the power port, which is connected to the rear of the power supply rack. The device monitors input and output conditions and uses relay contacts to report overrange failures and overtemperature/fan failures. The power port also allows the connection of an optional rack-mounted power controller for real-time configuration of output voltage and current, monitoring up to 12 power packs in 4 power racks
The system configuration tool supports MODBUS TCP unit ids 0 to 255
When configuring MODBUS TCP with Ethernet and port 502 selected
If selected, you can set a value from 0 to 255 for the cell ID.
Previously, the number was limited to one to 247.
Trusted toolset suite improvements
Many improvements have been implemented in Trusted
Toolset suite:
? Fixed bug behavior in the function block diagram program
? Fixed an issue with complex password configurations
? Fixed many user interface issues
Modbus slave station, TCP unit identifier used
Ethernet and MODBUS TCP slave on port 502 are selected
Values in the range 0 to 255 can be used for cell ids. Previous this
Is limited to 1 to 247.
8000 Series /CS300 Hybrid digital input Single slot hot repair
The CS300 digital input module has now been replaced by hot repair
