當需要對三相系統進行連續監測時，PQMII是理想的選擇。它提供了計量電流，電壓，實際和無功功率，能源使用，功率成本，功率因數和頻率?？删幊淘O(shè)定值和4個可分配的輸出繼電器允許為特定應用添加控制功能。這包括電流或電壓過/欠、不平衡、基于需求的減載和電容功率因數校正控制的基本報警。使用4個開關輸入可以實現更復雜的控制，也可以用于斷路器開/關、流量信息等狀
電壓擾動記錄器(VDR)監控電壓驟隆(電壓驟隆)和電壓尖峰(電壓上升)，容量為500次電壓聚降/電壓上升事件DNP 3.0通信協議標準特性。

PQMII-T20-C-A

特點和優勢
安裝多樣性
帶40字符大顯示屏的鍵盤
任何可分配的輸出可用于觸發報警
可連接至DCA或SCADA系統
閃存可升級
符合MultiNet串行到以太網轉換器
應用程序
配電饋線、變壓器、發電機、電容器組和電機的計量
中壓和低壓系統
商業、工業、公用事業
按需減載、功率因數等的靈活控制
電能質量分析工具
保護和控制

PQMII-T20-C-A

PQMII is ideal when continuous monitoring of three-phase systems is required. It provides metering of current, voltage, actual and reactive power, energy use, power cost, power factor and frequency. Programmable setpoints and 4 assignable output relays allow the addition of control functions for specific applications. This includes basic alarms for current or voltage over/under, unbalance, demand-based load shedding, and capacitor power factor correction control. More complex control can be achieved with four switching inputs, which can also be used for circuit breaker on/off, flow information, etc
The Voltage Disturbance Recorder (VDR) monitors voltage surges (voltage surges) and voltage spikes (voltage rises) with a capacity of 500 voltage drop/voltage rise events. DNP 3.0 communication protocol standard features
Characteristics and advantages
Installation diversity
Keyboard with large 40-character display
Any assignable output can be used to trigger an alarm
Can be connected to DCA or SCADA systems
Flash upgradable
Compliant serial to Ethernet converter
Application program
Metering of distribution feeders, transformers, generators, capacitor banks and motors
Medium and low pressure systems
Commercial, industrial, public utilities
Flexible control of on-demand load shedding, power factor, etc
Power quality analysis tool
Protection and control

PQMII-T20-C-A
