PFEA111產品編號: 3BSE050090R20 ABB型號名稱: PFEA111目錄描述: 張力電子產品PFEA111-2附加信息ABB型號: PFEA11核心信用證:0.00原產國:瑞典(SE)海關稅則號: 85389091毛重:0.2 k發票描述:張力電子產品PFEA111最小訂單量:1件訂單數量:1件包裝級別1總重量:0.2ko包裝級別1單位:1件露件類型:新產品名稱: Tension Electronics PFEA111產品凈重:0.2 僅限報價:無更換產品D(舊):3BSE028140R20銷售計量單位:件庫存(倉庫): 中央庫存美國SELOGREXPU技術信息:2個稱重傳感器輸入，電壓和電流輸出A+B，帶可調)波、顯示在顯示展A、B、A+B、A-B PFEA111上，包括CD用戶手冊UNSPSC:39120000 Global CommercialAlias;PFEA111
張力傳感器又叫張力檢測器，是一種在張力控制過程中，用來檢測紗線張力大小的儀器。本質上，張力傳感器也是一種稱重傳感器。

PFEA111-20

結構及工作原理:
張力傳感器的原理是在稱重傳感器的基礎上，利用兩個張力傳遞部件來傳遞力，力傳感器的內部結構是固定在壓電板中心區域的壓電板墊片的一側，壓電基片是位于另一側邊緣和力傳遞部分之間并靠近壓電板張力傳感器按其工作原理可以分為應變片型和微位移型。應變片型張力傳感器是張力應變片和壓縮應變片按照電橋方式連接在一起。應變片的電阻值會隨著外壓力的變化而變化，改變值的多少取決于壓力的大小。
而微位移型張力傳感器是通過外力施加負載，從而使板簧產生位移，然后通過差接變壓器檢測出張力，由于板簧的位移量極小，所以叫微位移張力檢測器。
根據不同拉力的強度和尺寸，設計了不同外形的張力傳感器，如S型張力傳感器，板環張力傳感器等。S型張力傳感器是最常用的機械傳感器，用于測量固體，大部分張力和壓力，通常稱為拉壓力傳感器，因?yàn)樗雌饋硐褚粋€(gè)S形，所以稱為S型張力傳感器上使用。
而張力傳感器多數采用三輪樣式的結構，為了不影響纜繩的運行所以在設計上也做到了堅固而緊湊的原理設計，測量重復度好，精度高，安裝簡便是基于三輪樣式的設計特點。而且中心輪的可移動性也便于安裝及運行

PFEA111-20

PFEA111 Product Number: 3BSE050090R20 ABB Model Name: PFEA111 Catalog Description: Tension electronic products PFEA111-2 Additional information ABB model: PFEA11 Core Credit :0.00 Country of Origin: Sweden (SE) Customs Code: 85389091 Gross Weight :0.2k Invoice Description: Tension electronic products PFEA111 Minimum order quantity :1 piece Order quantity :1 piece packaging level 1 Total weight :0.2ko packaging level 1 Unit :1 piece Exposure Type: New Product Name: Tension Electronics PFEA111 Product Net weight :0.2 Offer only: No Replacement Product D(old):3BSE028140R20 Sales Unit of measurement: Pieces Stock (warehouse): Central stock US SELOGREXPU technical information :2 load cell inputs, voltage and current output A+B, with adjustable) waves, displayed on display A, B, A+B, A-B PFEA111, Includes CD user manual UNSPSC:39120000 Global CommercialAlias; PFEA111
Tension sensor, also known as tension detector, is an instrument used to detect yarn tension in the process of tension control. In essence, the tension sensor is also a load cell.

Structure and working principle:
The principle of tension sensor is based on the weighing sensor, the use of two tension transfer components to transfer force, the internal structure of the force sensor is fixed in the center area of the piezoelectric plate on one side of the piezoelectric plate gasket, piezoelectric substrate is located between the other side edge and the force transfer part and close to the piezoelectric plate tension sensor according to its working principle can be divided into strain gauge type and micro-displacement type. The strain gauge type tension sensor is a tension gauge and a compression strain gauge connected together in a bridge mode. The resistance value of the strain gauge will change with the change of external pressure, and the amount of the change value depends on the size of the pressure.
The micro-displacement tension sensor is through the external force to apply the load, so that the spring displacement, and then through the differential transformer to detect the tension, because the displacement of the spring is very small, so called micro-displacement tension detector.
According to the strength and size of different tension, tension sensors of different shapes are designed, such as S-type tension sensor, plate ring tension sensor, etc. The S-type tension sensor is the most commonly used mechanical sensor for measuring solids, most of the tension and pressure, often called a tension sensor because it looks like an S-shape, so it is called an S-type tension sensor used on it.
The tension sensor mostly uses the structure of the three-wheel style, in order not to affect the operation of the cable, so the design has also achieved a solid and compact principle design, good measurement repetition, high accuracy, easy installation is based on the design characteristics of the three-wheel style. And the mobility of the center wheel is also easy to install and run.
