標準規模：輸出電壓0-400V、輸出電流0-300A、輸出功率3000W-6000W之內任選

2、恒壓恒流：電壓電流值從零至額定值連續可調

3、過流報警：電源輸出電流超越電流設定維護值時將聲光報警

4、過壓維護：電源輸出電壓超越電壓設定維護值時將跳閘維護

5、短路維護：允許在任何作業狀態下長時刻短路或短路開機

6、過載維護：電源或負載呈現毛病，電源跳閘維護

7、短路報警：當輸出電壓低于1%額定值時，電源聲光報警

8、輸出顯示：電壓、電流同時LED數碼顯示

9、脈沖作業：可配時刻控制器構成脈沖老到電源﹙選配﹚

10、智能化 ：可與計算機連接，組成計算機控制的智能化電源﹙選配﹚

PCD235A101

主要用途:

1、電解電容器老到，鉭電容器賦能

2、電阻器、繼電器，馬達等電子元件老到，例行實驗

3、實驗室，電子設備、自動測試設備

4、電子查驗設備、生產流水線設備、通訊設備

5、其它一切需求使用直流電源的場合

設有16檔等視點恒力矩細分，最高分辨率60000步/轉，使運轉滑潤，分辨率進步

2） 選用共同的控制電路，有效的降低了噪音，增加了滾動平穩性

3） 最高反應頻率可達200Kpps

4） 步進脈沖中止超越100ms時，線圈電流自動折半，減小了許多場合的電機過熱

5） 雙極恒流斬波方法，使得相同的電機可以輸出更大的速度和功率

6） 光電阻隔信號輸入/輸出

7） 驅動電流從0.6A/相到5.2A/相分16檔可調

8） 可以驅動任何5.8A相電流以下三相混合式步進電機

9） 單電源輸入，電壓規模：AC60-110V

10） 出錯維護：a) 過熱維護; b) 過流、電壓過低維護

11） 體積為68×108.5x178mm3,分量為2.0kgs

PCD235A101

Standard scale: Output voltage 0-400V, output current 0-300A, output power 3000W-6000W optional

2, constant voltage constant current: voltage and current value from zero to the rated value is continuously adjustable

3, overcurrent alarm: When the power output current exceeds the set maintenance value of the current, the audible and visual alarm will be issued

4, overvoltage maintenance: the power output voltage exceeds the voltage set maintenance value will trip maintenance

5, short circuit maintenance: allow long short circuit or short circuit boot in any working state

6, overload maintenance: power supply or load fault, power trip maintenance

7, short circuit alarm: when the output voltage is less than 1% of the rated value, the power supply audible and visual alarm

8, output display: voltage, current simultaneously LED digital display

9, pulse operation: can be equipped with a time controller to form a pulse to the power supply (optional)

10, intelligent: can be connected with the computer, composed of computer-controlled intelligent power supply (optional)

Main uses:

1, electrolytic capacitors are old, tantalum capacitors enable

2, resistors, relays, motors and other electronic components, routine experiments

3, laboratory, electronic equipment, automatic test equipment

4, electronic inspection equipment, production line equipment, communication equipment

5. All other occasions requiring the use of DC power supply

With 16 constant torque subdivision, the highest resolution 60000 steps/revolution, smooth operation, resolution improvement

2) Select a common control circuit to effectively reduce noise and increase rolling stability

3) The maximum reaction frequency can reach 200Kpps

4) When the stepping pulse is stopped beyond 100ms, the coil current is automatically halved, reducing the motor overheating in many occasions

5) bipolar constant current chopper method, so that the same motor can output greater speed and power

6) photoelectric blocking signal input/output

7) The drive current is adjustable from 0.6A/ phase to 5.2A/ phase in 16 stages

8) Can drive any three-phase hybrid stepper motor below 5.8A phase current

9) Single power input, voltage scale: AC60-110V

10) Error maintenance: a) overheat maintenance; b) Overcurrent and low voltage maintenance

11) The volume is 68×108.5x178mm3 and the component is 2.0kgs

PCD235A101
