配置:
?25 MHz MC68LC040微處理器
?4mb DRAM
?128kb sram
?1mb閃存
?(2)IndustryPack Ports
?(1)BIOS芯片已安裝
SCSI總線接口與32位本地總線突發DMA

部件編號:01-W3866B 43B
子卡部件號:01-W3913B 02A
特點:
雙高VME模塊
MC68LC040或MC68040微處理器
1MB、4MB或8MB的奇偶保護DRAM
512 kb SRAM

MVME162-213

艾默生/摩托羅拉MVME162是一種雙高VME模塊，配備MC68LC040或可選MC68040微處理器。(MC68040微處理器有一個浮點協處理器;MC68LC040則沒有。)MVME162具有1MB、4MB或8MB的奇偶保護DRAM;512KB SRAM(帶備用電池);一個TOD時鐘(帶備用電池);一個可選的局域網以太網收發器接口與DMA，兩個串行端口(EIA-232-D和EIA-232-D/EIA-530);6個帶有看門狗定時器的滴答計時器;可選的SCSI總線接口與DMA;VMEbus接口(本地總線到VMEbus/VMEbus到本地總線，具有A16/A24/A32, D8/D16/D32總線寬度和VMEbus系統控制器)。

MVME162-213

Settings:
?25 MHz MC68LC040 microprocessor
?4mb DRAM
?128kb sram
?1mb flash memory
?(2)IndustryPack Ports
?(1) The BIOS chip has been installed
SCSI bus interface with 32-bit local bus burst DMA

Part Number :01-W3866B 43B
Subcard Part number :01-W3913B 02A
Features:
Double height VME module
MC68LC040 or MC68040 microprocessor
1MB, 4MB, or 8MB parity protected DRAM
512 kb SRAM
The Emerson/MOTOROLA MVME162 is a dual-height VME module with the MC68LC040 or optional MC68040 microprocessor. The MC68040 microprocessor has a floating-point coprocessor; The MC68LC040 does not.) The MVME162 has 1MB, 4MB or 8MB parity protected DRAM; 512KB SRAM(with spare battery); A TOD clock (with spare batteries); An optional LAN Ethernet transceiver interface with DMA, two serial ports (EIA-232-D and EIA-232-D/EIA-530); 6 ticking timers with watchdog timer; Optional SCSI bus interface and DMA; VMEbus interface (local bus to VMEbus/VMEbus to local bus, with A16/A24/A32, D8/D16/D32 bus width and VMEbus system controller).

MVME162-213
