系統需求
MVI56-PDPMV1模塊需要以下最低硬件和
軟件組件:
?羅克韋爾自動化ControlLogix處理器，具有兼容的電源
在機架上有一個空閑槽，用于MVI56-PDPMV1模塊。該模塊
需要800ma的可用功率。
羅克韋爾自動化RSLogix 5000編程軟件版本2.51或
更高的
?羅克韋爾自動化RSLinx通信軟件
?Pentium?
II 450mhz最低。Pentium III 733 MHz(或更高)
推薦

MVI56-PDPMV1

屏幕上顯示安裝程序的說明。
安裝模塊到機架
如果您還沒有安裝和配置ControlLogix處理器和
請?jiān)诎惭bMVI56-PDPMV1模塊前關閉MVI56-PDPMV1的電源開關。請參考
警告:在安裝這個或任何其他電子設備時，您必須遵守所有安全說明
設備。不遵守安全程序可能會導致硬件或數據損壞，甚至導致設備損壞
人員嚴重受傷或死亡。請參考您計劃使用的每個設備的文檔
在安裝或維修設備之前，請連接以驗證適當?shù)陌踩绦蚴欠竦轿?br /> 設備。
警告:在背板通電的情況下插拔模塊時，會產生電弧
可能發生的。這可能會導致危險地點裝置的爆炸。驗證功率是否為
在進行前移除或該區域無危險。反復電弧的原因
模塊及其配套連接器上的觸點磨損過度。磨損的隱形眼鏡
產生可能影響模塊運行的電阻。

MVI56-PDPMV1

System requirement
The MVI56-PDPMV1 module requires the following minimum hardware and
Software components:
? Rockwell Automation ControlLogix processor with compatible power supply
There is a free slot in the rack for the MVI56-PDPMV1 module. This module
800ma of available power is required.
Rockwell Automation RSLogix 5000 Programming software version 2.51 or
higher
? Rockwell Automation RSLinx communication software
? Pentium ?
II 450mhz minimum. Pentium III 733 MHz(or higher)
Recommended

Instructions for installing the program are displayed on the screen.
Install the module into the rack
If you have not already installed and configured the ControlLogix processor and
Before installing the MVI56-PDPMV1 module, turn off the power switch of the MVI56-PDPMV1. Please refer to
Warning: You must follow all safety instructions when installing this or any other electronic device
Equipment. Failure to follow security procedures may result in damage to hardware or data, or even damage to the device
People are seriously injured or killed. Refer to the documentation for each device you plan to use
Before installing or servicing equipment, connect to verify that proper safety procedures are in place
Equipment.
Warning: Electrical arcs may occur when inserting or removing a module with power on the backplane
It could happen. This could lead to the explosion of a device in a dangerous location. Verify that the power is
Remove before proceeding or the area is not in danger. Cause of repeated arcing
Excessive contact wear on the module and its accompanying connectors. Worn contact lenses
Generates resistance that may affect module operation.

MVI56-PDPMV1
