The IS215VCMIH2C is designed as a VME communication card in the GE Mark VI turbine control system and is essential for the proper functioning of the entire system. VCMI The VME communication board supports the communication between the I/O card and other I/O cards installed on the VME backplane, I/O cards installed on the expansion rack, I/O backup protection module, triple-redundancy control module, main processor module, or main processor module.
The IS215VCMIH2C card is also widely known as the VME bus master controller. The PCB provides an interface for communication between the I/O board and the controller. It also acts as a communication interface for the System Control Network (IONet).
The IS215VCMIH2C has four ports connected on its front panel. These include an RS-232C serial port, type d plug connectors, and three IONet 10Base2 Ethernet ports. Each IONet connector is associated with three LED indicators labeled TX/RX/CD. The board has additional LED indicators (Status, Fail, Run, 1, 2, 4, 8). The former is located above the reset switch (button), while the latter is located directly below the serial port.
Each control module in the Mark VI system typically contains an IS215VCMIH2C, and these unique VCMI cards communicate with the main processor module to execute data through the control system’s application software. Due to the critical nature of the VCMI module, it is recommended to keep additional spare parts on the shelf to avoid the situation of machine downtime.
IS215VCMIH2C
