The main function of the IS215ACLEH1A is as a microprocessor-based controller. The model is part of a series of application control layer modules in the EX2100 series produced by GE Industrial Systems. The board is the first ACLE module, and is equipped with a peripheral component interconnect (PCI) controller and two Ethernet interfaces.

When the IS215ACLEH1A model is installed, it will be installed in the Innovation Series drive or EX2100 control rack. This board has several leds, these are the Active, OK, ENET, Status and Flash indicators, each with a different function, for example, the Active LED will be completely solid when the CPU(central processing unit) accesses the memory components. One of the software features of the IS215ACLEH1A model is the basic input/Output System (BIOS), which initializes and recognizes other hardware forms. The BIOS feature supports serial loading of the operating system.

Although the IS215ACLEH1A model was mostly obsolete at this time, it can still be found. The best manual to use with the IS215ACLEH1A model is the GEI-100434 Application Control Layer Module (ACL) Manual.

IS215ACLEH1A This module is a single socket CPU module with one CPU substrate and seven expansion and/or remote substrates. It uses the 80386EX processor type with a speed of 25MHz and operates at ambient temperatures of 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit). The typical scan rate of this CPU is.22 ms /K and the maximum user program memory is 32K bytes. It comes with a built-in serial port that supports SNP/SNP-X slave protocols and a LAN port that supports multipoint, Ethernet, FIP, Profibus, GBC, GCM, and GCM+ option modules. The controller supports shift registers, override, battery backup clock, PCM/CCM compatibility, periodic subroutine interrupt functionality, floating point math, RAM, and flash storage. It requires a +5 VDC power supply to provide 670 mA.

IS215ACLEH1A
