此處列出的設備是 9907-164 型號，是基于微處理器的 505 和 505E 調速器控制單元的一部分。這些控制模塊專為操作蒸汽輪機以及渦輪發電機和渦輪膨脹機模塊而設計。505/505E 系列最初由伍德沃德公司開發、生產和制造。伍德沃德是美國歷史最悠久的工業制造商，成立于 1870 年，時至今日仍然是市場上領先的工業公司之一。這些 505 和 505E 型號可從我們的 AX Control Inc. 獲得，作為我們二手但翻新和維修數字硬件庫存的一部分。

9907-164邊緣控制器設備利用了新的IT 通信和物聯網的技術，同時保留了PLC/PAC 在OT方面的 邊緣控制器的通信有兩個不同層面：一個是采集工業設備和過程數據的I/O，以及與其它工業控制設備通信，屬于OT范疇；另一個是邊緣設備與OT數據中心及云端服務器之間的通信，屬于IT的范疇，也即屬于工業互聯網的范疇。作為IT和OT之間的一個物理接口，在完成工作站或生產線的控制功能基礎上，提升工業設備的接口能力和計算能力，提高工業設備的適用性，所以在一定程度上能夠促進IT與OT的融合。因此，邊緣控制器多種技術的組合能夠滿足多種應用需求，因而非常適合工業應用。與傳統PLC不同，邊緣控制器能夠提供連接解決方案，包括充當OPC或消息隊列遙測傳輸（MQTT）服務器。

9907-164

9907-164 裝置設計用于通過操作汽輪機的單次抽汽和/或汽輪機來控制汽輪機。它利用渦輪機的分離級執行器(其中一個或兩個)來驅動蒸汽入口閥。

該單元與任何 505 調速器模塊一樣，可以由現場操作員在現場進行配置。菜單驅動的軟件由集成在設備正面的操作員控制面板控制和更改。該面板顯示兩行文本，每行 24 個字符。

9907-164 配備了一系列離散和模擬輸入：16 個觸點輸入(其中 4 個是專用的，其中 12 個是可編程的)，然后是 6 個可編程電流輸入，為 4 至 20 mA。9907-164 功能中包含的標準功能包括臨界速度回避、閥位限制器、自動啟動順序和停機先出指示器。

9907-164 505(傳統) 低壓直流，標準

前面板安裝的第二代用戶可配置蒸汽輪機數字調速器控制，帶 24 Vdc 電源輸入，額定為 1 類，Div。2 個標準位置?，F(xiàn)在升級到下一代直接替換 505D。(普通位置請參見項目編號 8200-1300，或 2 區位置請參見項目編號 8200-1302)

9907-164

The devices listed here are models 9907-164 and are part of the 505 and 505E governor control units based on microprocessors. These control modules are designed for the operation of steam turbines as well as turbogenerator and turboexpander modules. The 505/505E series was originally developed, produced and manufactured by the Woodward Company. Woodward is America’s oldest industrial manufacturer, founded in 1870, and remains one of the leading industrial companies in the market today. These 505 and 505E models are available from our AX Control Inc. Acquired as part of our used but refurbished and repaired digital hardware inventory.

9907-164 Edge controller equipment uses new IT communication and Internet of Things technology, while retaining PLC/PAC in OT edge controller communication has two different levels: one is the acquisition of industrial equipment and process data I/O, and communication with other industrial control equipment, belongs to the OT category; The other is the communication between edge devices and OT data centers and cloud servers, which belongs to the category of IT, that is, the category of industrial Internet. As a physical interface between IT and OT, on the basis of completing the control functions of workstations or production lines, the interface capability and computing power of industrial equipment are improved, and the applicability of industrial equipment is improved. Therefore, the integration of IT and OT can be promoted to a certain extent. Therefore, the combination of edge controller technologies can meet a variety of application needs, so it is very suitable for industrial applications. Unlike traditional PLCS, edge controllers are able to provide connectivity solutions, including acting as OPC or message queue telemetry Transfer (MQTT) servers.

The 9907-164 unit is designed to control a steam turbine by operating a single extraction and/or steam turbine. It uses one or both of the turbine’s separate stage actuators to drive the steam inlet valve.

The unit, like any 505 governor module, can be configured in the field by a field operator. Menu-driven software is controlled and changed by an operator control panel integrated on the front of the device. The panel displays two lines of text, each of 24 characters.

The 9907-164 is equipped with a range of discrete and analog inputs: 16 contact inputs (four of which are dedicated, 12 of which are programmable), followed by six programmable current inputs ranging from 4 to 20 mA. Standard features included in the 9907-164 feature include critical speed avoidance, valve position limiter, automatic start sequence, and stop-first out indicator.

9907-164 505(Traditional) Low voltage DC, standard

Front panel mounted second generation user configurable steam turbine digital governor control with 24 Vdc power input rated Class 1, Div. 2 standard locations. Now upgrade to the next generation direct replacement 505D. (Please refer to Project number 8200-1300 for common location, or Project number 8200-1302 for Zone 2 location)

9907-164
