基本細節: KDV2.2-100-200300-220 三相交流電壓轉換為驅動模塊的穩壓直流電壓

KDV 2.2-100-220/300-220 將三相交流電壓轉換為驅動模塊的穩壓直流電壓。它一次可以為多達十個驅動器供電。KDV 2.2-100-220/300-220 為所有連接的驅動模塊提供 +24V 和 ±15V 電壓。KDV 電源模塊可以以 24 kW 的連續機械輸出運行。連續再生功率可達 2 kW。
KDV 2.2-100-220-300-220 由 Rexroth、Indramat、Bosch 在 KDV 系列中提供。KDV 電源模塊為 Indramat 驅動器提供直流電源，該驅動器與 Indramat 控制器和伺服電機配合使用。這款 KDV 2.2-100-220-300-220 提供額定電流 100A，額定電壓為 AC 220V，直流母線標稱電壓為 DC 300V，散熱器鼓風機標稱電壓為 AC 220V。

KDV 系列中的其他模塊可以為有需要的應用提供更高的連續再生功率。
KDV電源模塊的背面安裝有一個散熱器，從機柜中伸出。因此，這些模塊80%的熱損失發生在機柜外部。如果您需要用于高功率應用的電源，但需要更小的尺寸，KDV 2.2-100-220/300-220 是一個絕佳的選擇。
應用的范圍：電氣布局\控制柜的機械布置
電源供應到驅動器:三相橋整流三相市電交流電壓，并為驅動器提供直流高壓。當驅動器處于發電機模式時，再生的能量被放血器吸收并轉化為熱量。緩沖電容提供足夠的平滑
電子設備電源:KDV 2.3為所有附加的驅動模塊提供+24V和±15V電源。在電源故障的情況下，信號電壓從電源接收它們的功率
直流總線。這意味著當驅動器處于發電機模式時，驅動電子設備仍然可以運行。
監控驅動系統:KDV 2.3配備了廣泛的監控功能。它們通過信號電壓總線與驅動模塊通信。Bb1接觸對驅動系統準備更重要。只有當觸點閉合時才能接通電源

KDV2.2-100-200300-220

The KDV 2.2-100-220/300-220 converts the three-phase AC voltage to the regulated DC voltage of the drive module. It can power up to ten drives at a time. The KDV 2.2-100-220/300-220 provides +24V and ±15V voltages for all connected drive modules. The KDV power module can operate with a continuous mechanical output of 24 kW. Continuous regeneration power up to 2 kW.
KDV 2.2-100-220-300-220 is provided by Rexroth, Indramat, Bosch in the KDV series. The KDV power module provides DC power to the Indramat driver, which is used in conjunction with the Indramat controller and servo motor. The KDV 2.2-100-220-300-220 offers rated current of 100A, rated voltage of AC 220V, DC bus nominal voltage of DC 300V, radiator blower nominal voltage of AC 220V.

Other modules in the KDV family can provide higher continuous regeneration power for applications that require it.
A heat sink is installed on the back of the KDV power module and protrudes from the cabinet. As a result, 80% of the heat loss of these modules occurs outside the cabinet. If you need a power supply for high power applications but need a smaller size, the KDV 2.2-100-220/300-220 is an excellent choice.
Scope of application: electrical layout \ mechanical layout of control cabinet
Power supply to the driver: The three-phase bridge rectes the three-phase mains AC voltage and provides the DC high voltage to the driver. When the driver is in generator mode, the regenerated energy is absorbed by the bleeder and converted into heat. Buffer capacitance provides sufficient smoothness
Power supply for electronic devices :KDV 2.3 provides +24V and ±15V power for all additional drive modules. In the event of a power failure, the signal voltages receive their power from the power supply
Dc bus. This means that the drive electronics can still operate when the drive is in generator mode.
Monitoring driver System: The KDV 2.3 is equipped with a wide range of monitoring functions. They communicate with the driver module via the signal voltage bus. Bb1 contact is more important for drive system preparation. Power can only be turned on when the contact is closed
