基本細節:

9907-163? 控制器 用于控制單或雙（分體式）執行器蒸汽輪機

9907-163 控制器設計用于控制單或雙（分體式）執行器蒸汽輪機（抽氣式蒸汽輪機需要 505XT 版本）。505 是現場可編程的，允許在許多不同的控制應用中使用單一設計，并降低成本和交付時間。Woodward Governor 使用菜單驅動軟件指導現場工程師將控制編程到特定的發電機或機械驅動應用。505 可以配置為作為獨立單元運行，也可以與工廠的分布式控制系統結合使用。
505 是一款現場可配置的汽輪機控制和操作員控制面板 （OCP），集成在一個套件中。505 的前面板上有一個全面的操作員控制面板，包括一個兩行（每個 24 個字符）顯示屏和一組 30 個按鍵。此 OCP 用于配置 505、進行在線程序調整和操作渦輪機/系統。OCP的兩行顯示屏以英文顯示易于遵循的說明，操作員可以從同一屏幕查看實際值和設定值。
9907-162 暖通空調 （180–264 Vac）
9907-163 交流/直流（88–132 Vac 或 90–150 Vdc）
9907-164 LVDC （18–32 V直流）
可選隔板安裝箱 （NEMA 4X） P/N 8923-439
9907-163、505 控制器現在使用特殊的聚丙烯酸酯保形涂層材料。因此，這種涂層可以保護其內部電路板免受腐蝕性環境的影響。這種新型聚丙烯酸酯材料取代了以前的有機硅保形涂層。這改善了電路板組件和硫基氣體之間的屏障。具有此涂層的 505 對照品的側面將有一個標簽，上面寫著“耐硫保形涂層”

9907-163

The 9907-163 controller is designed to control a single or dual (split) actuator steam turbine (a 505XT version is required for an extractive steam turbine). The 505 is field programmable, allowing a single design to be used in many different control applications and reducing cost and delivery time. Woodward Governor uses menu-driven software to guide field engineers in programming controls to specific generator or mechanical drive applications. The 505 can be configured to operate as a standalone unit or combined with a distributed control system in a plant.
The 505 is a field-configurable turbine control and operator control panel (OCP), integrated in a single package. The 505 has a comprehensive operator control panel on the front panel, including a two-line (24 characters each) display and a set of 30 keys. This OCP is used to configure the 505, make in-line program adjustments, and operate the turbine/system. The OCP’s two-line display displays easy-to-follow instructions in English, allowing the operator to view the actual and set values from the same screen.
9907-162 HVAC (180-264 Vac)
9907-163 AC/DC (88-132 Vac or 90-150 Vdc)
9907-164 LVDC (18-32 VDC)
Optional partition mounting box (NEMA 4X) P/N 8923-439
The 9907-163 and 505 controllers now use special polyacrylate conformal coating materials. As a result, this coating protects its internal circuit board from corrosive environments. This new polyacrylate material replaces the previous silicone conformal coating. This improves the barrier between the board components and the sulfur-based gas. 505 reference products with this coating will have a label on the side that reads “Sulfur Resistant Conformal Coating”
