基本細節:VPL-B21542-P-X256 伺服電機 低慣量

VPL-B21542-P-X256伺服電機，低慣量，460V AC，215mm螺栓圓框尺寸，4（四）磁鐵堆棧，800 rpm額定速度，多圈編碼器，鍵控軸，SpeedTec直角DIN，保持制動器，IEC公制安裝法蘭，標準
VPL-B21542-P-X256是一種低慣性伺服電機。伺服電機的電壓為400伏，框架尺寸為100毫米。VPLB21542-P-X256的額定轉速為每分鐘4，500轉，配有三個磁體組。VPL-B21542-P-X256的反饋類型是18位絕對單圈數字編碼器，配有軸鍵。VPLB21542-P-X256還具有單speedTEC DIN連接器和直角325度可旋轉連接器。VPL-B21542-P-X256的安裝法蘭是IEC公制自由安裝孔，是標準的工廠選項。VPL-B21542-P-X256的制動器類型為24伏DC。

VPL-B21542-P-X256的設計和制造符合Kinetix 5500硬盤的額定值，并采用單電纜技術。該模塊還具有較高的扭矩尺寸比，并且轉子慣性較低.VPL-B21542-P-X256是單圈和多圈絕對反饋裝置。它提供了高能稀土磁體和軸端螺紋孔。通過話當?shù)木S護，VPL-B21542-P-X256的使用壽命將會延長。因此，遵循制造商提供的正確設計和維護說明非常重要。VPL-B21542-P-X256和其他低慣性伺服電機具有各種繞組選項，與Kinetix 5500驅動器的額定值相匹配。優化的系統規模降低了系統成本并提高了能效。

VPL-B21542-P-X256

Servo motor, Low inertia, 460V AC, 215mm bolt round frame size, 4 (four) magnet stack, rated speed of 800 rpm, multi-turn encoder, keying shaft, SpeedTec right Angle DIN, holding brake, IEC metric mounting flange, standard
The VPL-B21542-P-X256 is a low inertia servo motor built by Allen Bradley of Rockwell Automation. The servo motor has a voltage of 400 volts and a frame size of 100 mm. The VPLB21542-P-X256 is rated at 4,500 revolutions per minute and is equipped with three magnet groups. The feedback type of the VPL-B21542-P-X256 is an 18-bit absolute single-turn digital encoder with shaft keys. The VPLB21542-P-X256 also features a single speedTEC DIN connector and a right Angle 325-degree rotatable connector. The mounting flanges of the VPL-B21542-P-X256 are IEC metric free mounting holes and are a standard factory option. The VPL-B21542-P-X256 has a 24 volt DC brake type.

The VPL-B21542-P-X256 is designed and manufactured to meet the ratings of Kinetix 5500 hard drives and uses single-cable technology. The module also has a high torque dimension ratio and low rotor inertia. The VPL-B21542-P-X256 is a single – and multi-turn absolute feedback device. It provides high-energy rare earth magnets and threaded holes at the end of the shaft. The service life of the VPL-B21542-P-X256 will be extended through the maintenance of the phone. Therefore, it is important to follow the proper design and maintenance instructions provided by the manufacturer. The VPL-B21542-P-X256 and other low inertia servo motors have a variety of winding options that match the ratings of the Kinetix 5500 drives. The optimized system scale reduces system costs and improves energy efficiency.

如果您需要查詢或購買，請將產品型號發送到我的電子郵件或直接致電我

銷售經理:何經理

手機: + 86 18005021035

郵箱:?18005021035@163.com

▲更多相關型號:VPL-B21542-P-X256 伺服電機 低慣量
