基本細節:2090-CSWM1DF-14AA09 專為Kinetix 5500伺服驅動器設計

2090-CSWM1DF-14AA09電纜以線圈的形式儲存和運輸。在拉直電纜之前，電纜保持這種形狀。要拉直電纜，可以從其中點懸掛一根短電纜，或?qū)⒁桓L(zhǎng)電纜沿直線放在地板上。在接下來的24小時內，電纜中的任何線圈都將被拉直。這種做法使電纜更容易安裝。

單根電纜使用的電纜技術是相同的，無論目錄號如何。每根電纜的不同之處在于引線準備和反饋導體端子..2090-CSxM1DF電纜導體具有飛引線和引線制備，專為Kinetix 5500伺服驅動器設計，不需要現場鉛準備.2090-CSxM1DE電纜包括2198-KITCON-DSL連接器套件。該套件與反饋導體預組裝，飛引線功率導體的引線準備是專門為Kinetix 5700伺服驅動器設計的。不需要現場鉛準備。
.2090-CSxM1DG電纜導體具有飛引線和引線制備，專為Kinetix 5500或Kinetix 5700同服驅動器設計。不需要現場引線準備，但是，2090-CSxM1DG電纜引線比2090-CSxM1DF電纜引線長，以適應任一驅動器系列。

這些數字說明了如何測量彎曲半徑和電纜彎曲的地方可以在單電機電纜上。在系統安裝過程中，布放電纜時，請與電纜引腳和規格表配合使用。
為了滿足Kinetix 5700伺服驅動系統上的電機制動電路的當前要求，電纜長度超過50米(164英尺)，2090-CSBM1DE(B系列)電纜可與18 AWG制武導體一起使用。B系列電纜設計用于電纜長度從51米(167英尺)到90米(294英尺)的應用，可提供1.0米(3.3英尺)的增量。對于需要1.0米(3.3英尺.)..50米(164英尺)電纜長度的Kinetix 5700驅動系統，2090-CSBM1DE(A系列)電纜仍然可用

2090-CSWM1DF-14AA09

Cables are stored and transported in the form of coils. The cable remains in this shape until it is straightened. To straighten a cable, either hang a short cable from its center point or place a long cable on the floor in a straight line. Over the next 24 hours, any coils in the cable will be straightened. This practice makes the cable easier to install.

The cable technology used by a single cable is the same regardless of the directory number. Each cable is different in lead preparation and feedback conductor terminals… The 2090-CSxM1DF cable conductor features fly leads and lead preparation, designed for Kinetix 5500 servo drives and does not require field lead preparation. The 2090-CSxM1DE cable includes the 2198-KITCON-DSL connector kit. The kit is pre-assembled with feedback conductors, and the lead preparation of the fly Lead power conductor is specifically designed for Kinetix 5700 servo drives. No field lead preparation required.
The.2090-CSXM1DG cable conductor has fly leads and lead preparation and is designed for Kinetix 5500 or Kinetix 5700 co-service drives. Field lead preparation is not required, however, the 2090-CSxM1DG cable leads are longer than the 2090-CSxM1DF cable leads to accommodate either drive family.

These figures illustrate how to measure the bending radius and where the cable can bend on a single motor cable. When routing cables during system installation, use the cable pins and specification table together.
To meet current requirements for motor brake circuits on Kinetix 5700 servo drive systems with cable lengths exceeding 50 meters (164 ft), the 2090-CSBM1DE(B Series) cable can be used with 18 AWG weapon conductors. The B-Series cables are designed for applications with cable lengths from 51 meters (167 ft) to 90 meters (294 ft) and are available in 1.0 meter (3.3 ft) increments. For 1.0 m (3.3 ft.) required. .. 50 m (164 ft) cable length Kinetix 5700 drive system, 2090-CSBM1DE(A Series) cable is still available.
