技術規格：
1. 數字/開關輸入：6 光隔離
2.最大環境濕度：高達 95% 的無冷凝
3.尺寸 約：11.5 英寸高 x 5.5 英寸寬 x 8.5 英寸長
4.顯示版本：增強
5.保險絲：3.15 A H 250 V
6.輸入功率：110-250伏直流電 100-240伏交流電

功能包括：
1.計量：369 可以監控電壓、瓦特、頻率和能量等量，并根據生成的值數據生成保護功能。
2.活動記錄：在行程結束后，369 能夠立即報告行程原因，以及行程時的溫度和數據值，使用戶能夠分析系統中出了什么問題。
3.行程前警報：當因接地故障、機械堵塞、RTD 過熱等原因?qū)е绿l時，369 可以在跳閘前通知用戶。
4.運動健康報告：繼電器可以使用學到的信息和系統跳閘的歷史記錄來確定何時何地可能需要維護。
5.振蕩法：在跳閘時觸發三個波形記錄，并捕獲 16 個數據周期。在此過程中，相電流和接地電流以及觸點輸入狀態都會被捕獲。
6.369-HI-R-M-0-0-E繼電器生成的大量數據和保護功能有助于減少故障排除時間并延長系統壽命，使其成為中型電機的絕佳選擇。

369-HI-R-M-0-0-E

Technical specifications:
1. Digital/switch input: 6 optical isolation
2. Maximum ambient humidity: up to 95% non-condensing
3. Dimensions: 11.5 inches high x 5.5 inches wide x 8.5 inches long
4. Display version: Enhanced
5. Fuse: 3.15AH 250V
6. Input power: 110-250 volts DC 100-240 volts AC

Features include:
1. Metering: 369 can monitor the equivalent of voltage, watt, frequency and energy and generate protection functions based on the generated value data.
2. Activity recording: At the end of the trip, 369 can immediately report the reason for the trip, as well as the temperature and data values at the time of the trip, enabling users to analyze what went wrong in the system.
3. Pre-trip alarm: When the trip is caused by ground fault, mechanical blockage, RTD overheating and other reasons, 369 can notify the user before the trip.
4. Sports health reports: Relays can use learned information and a history of system trips to determine when and where maintenance may be needed.
5. Oscillation method: Three waveform records are triggered when tripping, and 16 data cycles are captured. During this process, both the phase and ground currents are captured, as well as the contact input state.
The large amount of data and protection generated by the

6.369-HI-R-M-0-0-E relay help reduce troubleshooting time and extend system life, making it an excellent choice for medium-sized motors.
