MVI56E-DNPNET是一款以太網模塊。該模塊具有一個插槽，支持8000個二進制輸出，8000個二進制輸入，以及1000個計數器。它采用RSLogix 5000中的附加指令進行模塊的配置和設置，允許將配置數據存儲在PAC梯形圖代碼中。
MVI56E-DNPNET模塊的主要特點是具有一個集成的串行端口，支持RS-232、RS-485和RS-422（跳線可選）通信。串行端口與機架背板具有500伏額定光隔離，并提供握手控制。此外，該模塊還包括一個帶有RJ-45接口的10/100 Mbps以太網端口，支持自動交叉。
該模塊適用于工業自動化和控制系統領域，特別是那些需要DNP3以太網通信的應用。它可用于連接和通信與DNP3協議兼容的設備，實現數據的采集、傳輸和控制。

MVI56E-DNPNET

MVI56E-DNPNET is an Ethernet module. The module has a slot that supports 8,000 binary outputs, 8,000 binary inputs, and 1,000 counters. It uses additional instructions in RSLogix 5000 for module configuration and setup, allowing configuration data to be stored in PAC ladder code.
The main feature of the MVI56E-DNPNET module is that it has an integrated serial port that supports RS-232, RS-485 and RS-422 (jumper optional) communication. The serial port has 500-volt rated optical isolation from the rack backplane and provides handshake control. In addition, the module includes a 10/100 Mbps Ethernet port with an RJ-45 interface that supports automatic crossover.
The module is suitable for the field of industrial automation and control systems, especially those applications requiring DNP3 Ethernet communication. It can be used to connect and communicate with DNP3 protocol compatible devices to achieve data acquisition, transmission and control.
